Technical
Features
The
high
degree
of
modularity
is
a
design
feature
of
SRC
helical
gearboxes
range.It
can
be
connected
respectively
with
motors
such
as
normal
motor,
brake
motor,
explosion-proof
motor,
frequency
conversion
motor,
servo
motor,
IEC
motor
and
so
on.This
kind
of
product
is
widely
used
in
drive
fields
such
as
textile,
foodstuff,
ceramics
packing,
logistics,
plastics
and
so
on.It
is
possible
to
set
up
the
version
required
using
flanges
or
feet.
Products
characteristics
SRC
series
helical
gear
units
has
more
than
4
types.Power
0.12-4kw;
Ratio
3.66-54;
Torque
max
120-500Nm.It
can
be
connected
(foot
or
flange)
discretionary
and
use
multi-mounting
positions
according
to
customers
requirements.
Ground-hardened
helical
gears;
Modularity,can
be
combined
in
many
forms;
Aluminium
casing,
light
weight;
Gears
in
carbonize
hard,
durable;
Universal
mounting;
Refined
design,space
effective
and
low
noise
Structure feature
Model
illuminate
4.2
Rotation
speed
n
n1
Gear
units
input
speed
n2
Gear
units
output
speed
If
driven
by
the
external
gearing,1400r/min
or
lower
rotation
speed
is
suggested
so
as
to
optimize
the
working
conditions
and
prolong
the
service
life.Higher
input
rotation
speed
is
permitted,
but
in
this
situation,the
rated
torque
M2
will
be
reduced
4.5
Service
factor
fs
The
effect
of
the
driven
machine
on
the
gear
unit
is
taken
into
account
to
a
sufficient
level
of
accuracy
using
the
service
factor
fs.The
service
factor
is
determined
according
to
the
daily
operation
time
and
the
starting
frequency
Z.Three
load
classifications
are
considered
depending
on
the
mass
acceleration
factor.You
can
read
off
the
service
factor
applicable
to
your
application
in
following
figure.The
service
factor
selected
using
this
diagram
must
be
less
than
or
equal
to
the
service
factor
as
given
in
the
performance
parameter
table.
*
starting
frequency
Z:
The
cycles
include
all
starting
and
braking
procedures
as
well
as
change
overs
from
low
to
high
speed
SRC02..(HS)
Performance parameter
Helical gearbox outline dimension heet
SRC helical gearbox with motor mounting position and terminal box orientation
Package
1 pc / carton,several cartons / wooden pallet
