The SCDA128R & SCDA128R/N are designed Category 4 , ISO13849-1 and may configure as an automatic or manual reset.
Inputs:
The SCDA128R can be connected in three different input wiring configurations:one normally closed;two normally closed;or with two PNP connections from a light curtain.The SCDA128R checks for cross faulty across the two inputs, when connected in the two normally closed. The light curtain must perform the cross fault detection when connected to light curtains.Outputs:
There are three safety output that are normally open and one non-safety auxiliary output that is normally close.
Function Features:Category 4 per ISO13849-1
Cross fault monitoring
Three safety contacts
Light curtain,E-stop or safety gate applications
One auxiliary contacts
Removable terminals
Automatic/Manual Reset
