Main characteristics:
High and stable oxygen concentration
24 hour fully automatic operation
CE Class IIb Medical Device
Control / piloting by touch screen
Managed remotely
Quality of the oxygen produced:
The oxygen produced must comply with the specifications of the European Monograph.Generator equipped with a Paramagnetic / Electromagnetic / Zirconium Oxygen Analyzer
Concentration 93% +/- 3%
Water content < 67 ppm (-75°C)
CO < 5 ppm
CO2 < 250ppm
SO2 < 1 ppm
NO2 < 2ppm
Oil < 0.1 mg / m3
Water vapor < 67 ppm V/V
The medical oxygen generator shall be controlled and monitored
by an automated system.i)The controller must monitor the output oxygen pressure
ii)Show real time values and trending curves for oxygen purity and pressure.iii)Record 24/7 data.iv)Indicate preventative maintenance automatic warnings.v)Indicate historical logging of all alarms.vi)Indicate when the plant is in standby mode.vii)Allow automatic permutation and automatic start/stop function capabilities in case of combination of two or more generators.
