12.5kg 15kg LPG Gas Cylinder Production Line
We have different types of
Burning furnance for LPG Cylinder Recondition Equipment

1.De-coil and punching machine
For small round sheet cutting from big sheet(material preparing for shell) ( with mould): 2pcs/per punching, 8pcs/minute.2. Power press drawing the head
Press the round sheet into a shell with dies.Blank holder force: 1000KN
Tensile force: 2000KN
Main motor power: 44KW
Maximum slider stroke: 700mm
The beading slide block stroke: 400mm
The weight of the machine: 12tons
3. Automatic trimming machine
This machine is reliable, easy to operate.Motor power: 5.5KW
The air pressure: 0.6Mpa
Process time: 20s
The weight of machine: 1.5tons
4.End dish necking cleaning machine
Motor power:7KW
Air pressure:0.6Mpa
Process time:15s
The weight of machine:1.5Tons
5.Hole punching machine
Punch the hole on head of the cylinder
Electric power: 5.5KW
Punching speed: 180pcs/hour
Weight of machine: 1.5ton
6.Valve Seat Welding Machine
To complete the welding of valve seat ring joints. Ensure uniform forming, good appearance, weld penetration and weld width meets the technological requirements, the clamping is convenient. Using submerged arc welding technology, girth welding at one time
7. Handle welding machine
Complete cylinder base girth automatic welding. To ensure concentricity, uniform forming, good appearance, weld penetration and weld width meet the technological requirements, the clamping is convenient. CO2 gas shield welding process, complete in one time welding.8. Bottom base welding machine
Motor power: 0.55KW
Air pressure: 0.5-0.7Mpa
Voltage: 380V
Welding speed: 15s/pcs
Weight of machine: 1.5ton
Thickness of steel sheet: 2-4mm
9. Assembling Machine
To assemble both halves of the cylinder together and get ready for welding
Motor power: 0.25KW
Air pressure: 0.5-0.7Mpa
Voltage: 220V
Weight of machine: 1.5ton
10. Auto circumferential welding machine
Motor power: 0.55KW
Air pressure: 0.6Mpa
Voltage: 380V
Welding speed: 120s/pcs
Weight of machine: 1.5ton
Thickness of steel sheet: 2-4mm
11. Heat treatment
Production speed: 75pcs/hour
Feeding type: chain drive feeding, cylinder feeding
Size of cylinder available: 320*700-420*1250mm
Size of machine:125000*1390*1560mm
12. Hydro Testing Machine
13. Drying machine
14. Shot Blasting Machine
Hook quantity unit: 2pcs
Loading weight: 2*600kg
No. of blasting machine: 2 sets
Working efficiency: 150-200pcs/hour
Total power: 35K
Working voltage: 380V 50Hz
Weight of machine: 16ton
15.Zinc Metalizing Machine
Arc spraying zinc machine total power: 15KVA*N
Vacuum cleaner engine power: 5.5KW
The compressed air input pressure: 0.55~7Mpa
Diameter of the zinc wire: 2-3mm
Rated input voltage: 220V~280V
Productivity: Max. 90 pcs/hour
Zinc wire consumption: 93 kgs/hour
16. Powder Coating Line
Working voltage: 380V, 50Hz
Air pressure: 0.4~0.6Mpa
Tower power: 15KW
Working effiency: 180pcs/hour
17. Printing machine
Printing size(L*W): 700*600mm
Production efficiency: 2pcs/min
Ink consumption: ≤2g/pc
Weight: 0.5T
18. Valve mounting machine
Motor power: 2.2KW
Speed ratio: 1:59
Voltage: 220V
Welding speed: 24rpm
Weight of machine: 0.9ton
19. Air leakage testing machine
Air pressure: 0.6Mpa
Air test pressure: 2.2Mpa
Holding time: 60s
Motor power: 3KW?
Weight of machine: 1.8ton
Size of cylinder available: 320*700-420*1250mm

Ningbo Mengkwa Machinery Co.,Ltd is an experienced and professional manufacturer of plastic extruder and extrusion lines for years. We can produce various equipments, including plastic pipe extrusion lines, plastic profile extrusion lines, plastic sheet/plate extrusion lines and also some recycling and pelletizing machines etc. According to different requirement s
of each customer, our engineers will provide most professional mechanical design and manufacturing, and the complete processing technology to meet their special application requirements.
If you want to know any information about us and machine or equipment, please contact with us at any time .
Ningbo Mengkwa Machinery Co. Ltd
Ningbo, China
web:
mengkwa.en.made-in-china.com
After-sale service
1.24 hours technical support by email, call, video.
2.
Warranty for one year after 12 months of shipment
3. Installation and commissioning engineer will provide the tech long machine, and machine operation of the buyer's personnel on-site training, troubleshooting and machine maintenance. The factory offers free installation training for a
week the company engineers, beyond a
week, the salaries borne by the customer engineer the factory.
Terms of payment
1.after receiving the deposit 40%, our company will arrange production
;
2.After the customer check and accept compression machine, before delivery, customer need to pay off the balance payment;
