基本信息产品详情证书
基本信息
型号编号 | 超薄热收缩管 |
头部代码 | 环形 |
材料 | 塑料 |
运输包 | 袋 纸箱 |
规格 | 十六分之三 |
起源 | 中国 |
商品编码 | 3917310000 |
生产能力 | 每天五万件 |
产品详情
Product Description
Preview
Heat shrinkable thin wall tube is halogen-free, flexible, flame-retardant polyolefin tubing.
Function
:wire coat and insulation make the joint of terminal block and wire insulated divide the colors Water-proof Protection and insulation.
Standard color
:black,white,red,blue,yellow,green,brown,grey,orange and purple.
It is low smoke generating, abrasion resistant and in case of burning, produces no dioxin.
It is perfect for electrical and electronics application and has uses widely in aerospace, automotives, construction, power delivery, and mass transit vehicles.
Halogen-free non-flame-retardant heat-shrinkable tube is made of radiation-crosslinked polyolefin material with excellent physical and chemical electrical properties. Products halogen-free environmental protection, widely used in automobiles, electronics, consumer goods, decoration and lighting and other fields. Product features: L Implementation Standard: UL224, cAN22.2 NO198.1-99L thermal shrinkage ratio: 2:1 l halogen-free, low smoke, non-toxic, soft L initial contraction temperature: ≥ + 70 ° CL complete contraction temperature: ≥ + 105 ° CL operating temperature: -55 ° C ~ + 105 ° CL Environmental Protection Standards: RoHS, IPCJEDEC-J-STD-709, Class H Materials L standard colors: transparent, black, white, red, yellow, green, blue, etc. . Ten International Standard CSA
Function
:wire coat and insulation make the joint of terminal block and wire insulated divide the colors Water-proof Protection and insulation.
Standard color
:black,white,red,blue,yellow,green,brown,grey,orange and purple.
It is low smoke generating, abrasion resistant and in case of burning, produces no dioxin.
It is perfect for electrical and electronics application and has uses widely in aerospace, automotives, construction, power delivery, and mass transit vehicles.
Halogen-free non-flame-retardant heat-shrinkable tube is made of radiation-crosslinked polyolefin material with excellent physical and chemical electrical properties. Products halogen-free environmental protection, widely used in automobiles, electronics, consumer goods, decoration and lighting and other fields. Product features: L Implementation Standard: UL224, cAN22.2 NO198.1-99L thermal shrinkage ratio: 2:1 l halogen-free, low smoke, non-toxic, soft L initial contraction temperature: ≥ + 70 ° CL complete contraction temperature: ≥ + 105 ° CL operating temperature: -55 ° C ~ + 105 ° CL Environmental Protection Standards: RoHS, IPCJEDEC-J-STD-709, Class H Materials L standard colors: transparent, black, white, red, yellow, green, blue, etc. . Ten International Standard CSA
Preview

Preview

Preview

Preview

Preview

Preview

Preview
证书
标题:WLS-15/3.3
