基本信息
| 型号编号 | GL-DY046 |
| 结构形式 | 表面天线 |
| VSWR | 2, <2 |
| PCS/CTN是包装代码的名称，具体含义为：商品（PCS）和装箱数量（CTN）。 | 二百 |
| 重量/箱 | 12.5 |
| 连接器 | SMA |
| 用法 | 汽车天线 |
| 使用场合 | 汽车天线 |
| 工作波长 | 微波炉 |
| 基本天线 | 高增益天线 |
| 交通一揽子计划 | 48*30*28厘米 |
| 规格 | 59.2*52.5*15.3毫米 |
| 商标 | 雷恒 |
| 起源 | 中国 |
| 商品编码 | 8529109090 |
| 生产能力 | 每天3000件 |
| 包装尺寸 | 53.00厘米 * 23.00厘米 * 29.00厘米 |
| 包装总重量 | 20.000千克 |
| 包装尺寸 | 53.00厘米 * 23.00厘米 * 29.00厘米 |
| 包装总重量 | 20.000千克 |
产品详情
Product Description
Preview
Preview
Preview
Preview
Applications
Automobile Navigation,
Logistics Positioning and etc.
Features
High stability,
Linearity,Consistency,
High gain,
outside-band interference suppression,
Low Noise Figure
Automobile Navigation,
Logistics Positioning and etc.
Features
High stability,
Linearity,Consistency,
High gain,
outside-band interference suppression,
Low Noise Figure
Preview
FAQ
Preview
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS Antenna
100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working
days for the sample, 10-15 working
days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, western union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
A: Yes, sample is available.
Q: Have GNSS Antenna
100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working
days for the sample, 10-15 working
days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, western union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
