225*99mm Waterproof IP55 Fan Ec-AC Backward Curved Centrifugal Fan
Model:PB3N225B2E-TG0
PBM
is a China mainland EC(Electronically Commutated) brushless motor manufacturing and technology consulting company offering an extensive range of EC motors, fans and intelligent ventilation solutions for air-moving precisely and constantly with maintenance-free throughout the life cycle of products in last decades.PBM fans are widely used in many fields. For example, axial fan for telecom, backward curved centrifugal fan for air exchanger,(inline duct fan)hydroponic products and FFU, forward curved centrifugal fan for air purifier and air conditioning,blower for kitchen.Product Description
1.General Characters
Rated Voltage
230 VAC
Frequency
50/60
Hz
Operating Voltage
184~276
VAC
Rated Speed
2300
RPM
Input Current
0.6
A
Input Power
85
W
Air Flow
573.79
CFM /
975
m3/H
Static Pressure
2.48
inH2O / 620
Pa
Acoustical Noise
65
dB(A)
Life Expectance
50,000
Hours(L10)At 40ºC room, humidity 15%~65%RH.Insulation Class
Class B
Motor Protection
Locked rotor protectionPolarity protectionAutomatic restart capability
Speed Control
Control input 0~10VDC / PWM
Protection Type
IP55
Signal Output
FG (Frequency Generator)
2.Mechanical Characters
Dimension
Ø225mm X 99mm (see dimension drawing)
Material of Impeller
PA66+GF
Number of Blades
7
Bearing System
NMB ball bearing
Lead Wire
AC(AWG20#),DC(AWG24
#)
3.Environmental Characters
Operating Temperature
-25ºC to 60ºC
Storage Temperature
-40ºC to 75ºC
Operating Humidity
5% to 90% RH
Storage Humidity
5% to 95% RH
4.Outline Drawing
Note:
1.Connection line: AC(3×AWG20#),DC(4×AWG24#)
2.AC: Brown=Live Line,Blue=Null Line,Green & Yellow=Protecting Earthing;
3.DC: Red=Voltage Output +10VDC, Yellow=0-10VDC/PWM, White=FG, Blue=GND;
5.Performance Curved
Testing Condition:
Input Voltage----Operating voltage (230VAC/50Hz)
Temperature-----Room temperature
Humidity---------65%RH
Application Scopes
Related Products
280*280*80mm Waterproof
250*74.2mm Waterproof IP55
160*100mm Waterproof IP55
48VDC Dual Inlet
Centrifugal
IP55 Fan Ec-AC Axial Fan
Fan Ec-AC Axial Fan
Forward Curved Centrifugal Fan
Blower Fan with 146mm
Impeller
FOB Price:US $51.4-57.4/Piece
FOB Price:US $40.7-45.5/Piece
FOB Price:US $51.2-57.2/Piece
FOB Price:US $52-58/Piece
Contact Now
Contact Now
Contact Now
Contact Now
225*99mm Waterproof IP55
140 Single Inlet Ec Centrifugal
175*95mm Ec-AC Backward
310*149.5mm Ec-AC Backward
Fan Ec-AC Backward Cur...Air Blower Fan
Centrifugal Fan for HVAC
Curved Centrifugal Fan
FOB Price:US $53.1-59.3/Piece
FOB Price:US $49-56/Piece
FOB Price:US $45.2-48.88/Piece
FOB Price:US $73.95-75.78/Piece
Contact Now
Contact Now
Contact Now
Contact Now
Products of the same series
Model
Motor
Rated Current
Rated Power
Rated Speed
Weight
Protection Type
Sound Level
Air Flow
Air Pressure
PB3N133B2EH
BE72EC
0.33 A
48 W
4480 RPM
1.06 KG
IP44
75 dB(A)
460 m³/h
475 Pa
PB3N175B2EH
BE72EC
0.85 A
105 W
4460 RPM
1.35 KG
IP44
76 dB(A)
810 m³/h
744 Pa
PB3N190B2EM
BE72EC
0.7 A
93 W
3570 RPM
1.45 KG
IP44
72 dB(A)
795 m³/h
686 Pa
PB3N190B2EH
BE92EC
1.0 A
140 W
4000 RPM
1.45 KG
IP44
74
dB(A)
800 m³/h
882 Pa
PB3N220B2EM
BE72EC
0.8 A
95 W
3060 RPM
1.68 KG
IP44
71 dB(A)
1080 m³/h
648 Pa
PB3N220B2EH
BE92EC
1.18 A
170 W
3060 RPM
2.5 KG
IP44
76 dB(A)
1100 m³/h
840 Pa
PB3N225B2EM
BE72EC
0.4 A
55 W
2200 RPM
1.74 KG
IP44
66 dB(A)
1065 m³/h
347 Pa
PB3N225B2EH
BE92EC
1.04 A
135 W
3020 RPM
2.8 KG
IP44
71 dB(A)
1340 m³/h
705 Pa
PB3N250B2EL
BE92EC
0.9 A
123 W
2760 RPM
2.15 KG
IP44
71 dB(A)
1290 m³/h
690 Pa
PB3N133B2E-RB2
BE72EC
0.3 A
43 W
4400 RPM
0.65 KG
IP55
70 dB(A)
415 m³/h
450 Pa
PB3N175B2E-RZ0
BE72EC
0.6 A
72 W
4050 RPM
1.3KG
IP55
72
dB(A)
710 m³/h
550 Pa
PB3N175B2E-SZ0
BE72EC
0.75 A
110 W
4600 RPM
1.5KG
IP55
74
dB(A)
700 m³/h
800 Pa
PB3N190B2E-RZ0
BE72EC
0.4 A
52 W
2940 RPM
1.35KG
IP55
65 dB(A)
540 m³/h
450 Pa
PB3N190B2E-RZ1
BE72EC
0.6 A
70 W
3300 RPM
1.35KG
IP55
70 dB(A)
800 m³/h
790 Pa
PB3N190B2E-SZ0
BE72EC
0.8 A
110 W
3800 RPM
1.45KG
IP55
71 dB(A)
810 m³/h
850 Pa
PB3N190B2E-TZ0
BE72EC
1.2 A
170 W
4550 RPM
1.85KG
IP55
72 dB(A)
945 m³/h
1000 Pa
PB3N220B2E-RZ0
BE72EC
0.65 A
85 W
2670 RPM
1.6 KG
IP55
68 dB(A)
960 m³/h
760 Pa
PB3N220B2E-SZ0
BE72EC
0.8 A
110 W
3100 RPM
1.7 KG
IP55
69 dB(A)
1000 m³/h
580 Pa
PB3N220B2E-TZ0
BE72EC
1.2 A
170 W
3500 RPM
2.45 kg
IP55
70 dB(A)
1255 m³/h
1010 Pa
PB3N225B2E-RG0
BE72EC
0.6 A
85 W
2300 RPM
1.52 KG
IP55
65 dB(A)
975 m³/h
620 Pa
PB3N225B2E-RG1
BE72EC
0.75 A
100 W
2450 RPM
0.52 KG
IP55
66 dB(A)
1100 m³/h
720 Pa
PB3N225B2E-SG0
BE72EC
0.8 A
110 W
2600 RPM
1.65 KG
IP55
68 dB(A)
1150 m³/h
750 Pa
PB3N225B2E-TG0
BE72EC
1.2 A
170 W
3200 RPM
2.47 KG
IP55
71 dB(A)
1300 m³/h
1000 Pa
PB3N225B2E-MG0
BE92EC
1.6 A
220 W
3500 RPM
3.1 KG
IP55
72 dB(A)
1350 m³/h
900 Pa
PB3N250B2E-RZ0
BE72EC
0.65 A
85 W
2100 RPM
1.72 KG
IP55
62
dB(A)
1150 m³/h
610 Pa
PB3N250B2E-SZ0
BE72EC
0.85 A
115 W
2350 RPM
1.82 KG
IP55
68 dB(A)
1250 m³/h
600 Pa
PB3N250B2E-TZ0
BE72EC
1.2 A
170 W
2750 RPM
2.42 KG
IP55
71 dB(A)
1500 m³/h
915 Pa
PB3N250B2E-MZ0
BE92EC
1.6 A
220 W
3100 RPM
3.42 KG
IP55
72 dB(A)
1600 m³/h
750 Pa
Application Scopes:Ventilation
&
Purification /
Air
Conditioning /
Refrigeration /
IT
&
Electronic
Industry /
Medical
Industry /
Heating /
Automotive
Industry /
Household
Electric
Appliances /
Cloud
Date
Center /
Mechanical
Equipment
and
Systems.Our Advantages
About PBM:High Quality EC Fan / Competitive Price / Strong Team / Long Life Expectance / Fast Delivery / Customization Available / Attentive Service / Professional Assistance
PBM Products Series
Laboratory
/
Packing Method
/
Workshop
/
Warehouse
FAQ
Frequently Asked Question
Q: What are electronically commutated motors?
Electronically Commutated motors are brushless DC motors where the direction of the electric current is switched using electronic controllers. As the switching of the current is technically known as 'commutating', brushless motors are also called 'electronically commutated' motors. EC motors provide the advantages of brushed DC motors in terms of the ability to have variable speed control, but without the drawbacks of brushes.Q: What are the advantages of EC motors?
EC motors are very high efficiency electric motors (80%) and maintain a high efficiency level at part speed. This means that in most cases they use less than one third to half of the electricity used by
traditional induction motors, which in turn translates into lower operating costs and short payback periods. As EC motors have a higher efficiency this ensures that the motors run cooler in application which ensures a longer life for the motor.In terms of speed control and features, because the motor's operation is controlled by software, EC motors allow customers to optimize and integrate the motor, fan and controller with the application, and to include features like data communications, constant volume control, variable speed.Features & Advantages
Q: What about cost?
The initial outlay for an EC motor is more expensive than the traditional induction / shaded pole motors and this is mainly due to the electronic components required to drive the commutation. In recent years the cost of electronic components has reduced dramatically as volumes increase.The huge energy savings provided by EC motors, mean equally large savings in operating costs, which in turn translate in payback periods as short as a few months combined with a longer life expectancy.In our case, together with high energy savings, low use of raw material, low part count and simple electronics, have allowed us to make our motor price very competitive.Q: How are EC motors 'sustainable'?
The huge energy savings provided by our EC motors directly translate into large carbon emissions savings.By using an EC motors in your application we are able to assist our customers in dramatically reducing the air pollution (CO2) generated by their applications. This is due to the motors high efficency & low energy costs which helps to preserve the world for a 'greener' future.EC Motors are designed & manufactured using 70% less copper and 80% less steel than traditional induction and shaded pole motors which has a dramatic reduction in environmental impact in producing these raw material components.services to the clients.Contact Us
We highly appreciate your any enquiry by email, call or instant message.
