Tube Fittings
A
fitting
or
adapter made by Hongji Instrument& Valve Manufacturing Co., Ltd.is used in pipe systems to connect straight sections of
pipe
or
tube, adapt to different sizes or shapes, and for other purposes such as regulating (or measuring)
fluid
flow.These fittings are used in
plumbing
to manipulate the conveyance of water, gas, or liquid waste in domestic or commercial environments, within a system of pipes or tubes.
pipe
tube
fluid
plumbing
1. Forged Stainless Steel Tube Fitting Features& Applications:
frequently used in structural applications.Pressure and temperature are the most critical operational criteria for tube fitting.Tube fitting materials are frequently chosen in conjunction with tubing materials.Connection Methods among tubes and fittings are chosen based on media, pressure, and temperature properties.
2. Variety of Tube Fittings(Forged Stainless Steel, bearing pressure and temperature):
Body Type: Elbow, union, straight, tee, cross, reducer.
Connection end: Welding, dual ferrules, threads, flange.
3. Tube Fitting General Data(Forged Stainless Steel, bearing pressure and temperature):
Pressure Range: 3000Psi-6000Psi(2064Bar-4133Bar)
Working temperatures: -54°C-649°C
Size:1/8''-1'',DN6-DN20
Connection: Dual Ferrules, Flange, Thread, Welding.Application: Liquid or Gas, Steam, Water
Body Material:304, 1316,316L, 321, Alloy
4. Industrial Application
Oil& Gas
Power Plant
Nuclear Energy
Petrochemical
Chemicals
Water Treatment
Semi-Conductor
Food& Beverage
Product Parameters

Hongji Instrument& Valve Manufacturing Co., Ltd. Was founded in 2009. The campus of Hongji Instrument& Valve Manufacturing Co., Ltd. Covers approximately 46000 square-meter lands and is located in Tianchang City, Anhui Province, China. Our plants and office buildings have been established on a high standard level and applied to the ISO quality system to ensure the products we build and the service we provide meet the highest requirement. Our company has committed to producing forged stainless steel or alloy ball valves, needle valves, valve sets, pipe unions, air distributors, and welded joints. With years of dedication, we have developed and maintained a good business relationships with many leading companies in different industries, Such as Qinshan Nuclear Power Plant. Conventional Island Nuclear Power Plant, Siemens, Ningde Chemical, PetroChina,
CNOOC, Saudi oil fields, etc., in order to fulfill the increasing needs in terms of harsh application usage from our client side, Hongji has made a partial acquisition of another valve plant in 2020, the engineering and technical team members have been increased up to 8 personals, total manufacturing capacity includes 36 CNCs, 28 high precision horizontal lathes, to utilize the fine manufacturing process effectively. Our target aims to provide clients with the best products and services.

1. Can I get a Sample?
We do provide some small specific samples accordingly based on the process we situate in.
2. Do you provide customized products?
We are good to offer customized services in terms of logo labeling, manufacturing based on samples or blueprints, etc.
3. Will communication be a problem?
Our sales team had great knowledge of our products and acquired solid English communication skills in both written and speaking; the communication can be accessed either literally or verbally via any social networking platform.
4. Payment Method.
L/C, T/T, PayPal, Western Union, etc.Principally we do not accept third-party transactions via China's mainland region channel.
5. Why Choose us?
Quality: 100% leakage, material, and functionality test in process and before shipping.Variety:
Highly customizable flexibility.Reliability:15 years of manufacturing experience.Efficiency: Quick& Effective response.Utility: Direct link from Manufacturer.Flexibility:
OEM/ODM are provided.Authentication: Real-time plant audit provided.Competitiveness: Price is negotiable on large volumes.
