Product
:
Nylon Nail Anchor
Category
: Anchor
Description
: Nylon Nail anchors are ideal for a wide variety of light load fastening in wood. Hardboard, plaster, metal, cinder block, brick, slate, marble, plastic, tile, glass, and concrete. Its unique design allows the nail to expand the anchor uniformly in the hole.
Technical properties
1. The anchor body is manufactured from virgin nylon to withstand high impact or shock loads. Its great tensile strength makes it unusually resistant to vibration loads.
2. The nylon is resistant to chemicals, fungus, moisture, and other atmospheric conditions.
3. Electrical and thermal insulating properties are excellent. Thermal resistance ranges from -40oF+170oF.
4. The pin is made of high-strength steel and heavily zinc-plated for maximum corrosion resistance.
ITEM CODE ANCHOR SIZE BOX QTY MASTER QTY
NNA3161 3/16X1 100 10
NNA316112 3/16X1-1/2 100 10
NNA1434 1/4X3/4 100 10
NNA141 1/4X1 100 10
NNA14112 1/4X1-1/2 100 10
NNA142 1/4X2 100 10
NNA143 1/4X3 100 10
NNA144 1/4X4 100 10

ITEM CODE ANCHOR SIZE DRILL SIZE SCREW SIZE
NNAL530 5X30mm Ø5mm 3.5X38mm
NNAL540 5X40mm Ø5mm 3.5X48mm
NNAL550 5X50mm Ø5mm 3.5X58mm
NNAL640 6X40mm Ø6mm 4X48mm
NNAL660 6X60mm Ø6mm 4X64mm
NNAL680 6X80mm Ø6mm 4X88mm
NNAL860 8X60mm Ø8mm 5X65mm
NNAL880 8X80mm Ø8mm 5X85mm
NNAL8100 8X100mm Ø8mm 5X105mm
NNAL8120 8X120mm Ø8mm 5X125mm
NNAL10100 10X100mm Ø10mm 7X110mm
NNAL10135 10X135mm Ø10mm 7X145mm
NNAL10160 10X160mm Ø10mm 7X170mm
