基本信息
型号:NO. | GEJ30 |
生产过程 | 半导体集成电路 |
材料 | 金属 |
准确度等级 | 0.5G |
IP等级(IP Rating) | |
认证 | ISO |
定制的 | 非定制的 |
运输包 | 木箱 |
规格说明 | 长×宽×高:211毫米×197毫米×405毫米 |
商标 | 味塔 |
起源 | 中国安徽省淮南市 |
生产能力 | 每年一万件 |
产品详情
Product Description
Preview
Deviation Sensor of Mine Flameproof Intrinsically Safe Belt Conveyor
1.Product use
GEJ30 deviation sensor is suitable for underground coal mine, open-pit coal mine and coal preparation plant. It is used to detect the deviation protection signal of mine belt conveyor comprehensive protection device.
2. Functional features
2.1. The product has the advantages of simple wiring, less explosion loss points and easy maintenance;
2.2. The sensor has high sensitivity;
2.3. The product has good sealing, moisture proof, simple and reliable operation and small maintenance amount;
2.4. It can realize the real-time positioning function of deviation;
1.Product use
GEJ30 deviation sensor is suitable for underground coal mine, open-pit coal mine and coal preparation plant. It is used to detect the deviation protection signal of mine belt conveyor comprehensive protection device.
2. Functional features
2.1. The product has the advantages of simple wiring, less explosion loss points and easy maintenance;
2.2. The sensor has high sensitivity;
2.3. The product has good sealing, moisture proof, simple and reliable operation and small maintenance amount;
2.4. It can realize the real-time positioning function of deviation;
Preview

Preview
3. Technical parameters
3.1. Contact capacity: 24 V / 0.5 A;
3.2. Contact resistance: the contact resistance of closed contact shall not be greater than 0.1 Ω, and shall not be greater than 0.2 Ω after vibration, impact and service life;
3.3. Movement angle: 30 °± 3 °, reset angle: 10 °± 3 °;
3.4. Action force of probe rod: 25n-100n;
3.5. The limit angle of probe rod rotation is not less than 70 °
4. Working principle
The deviation detection rod of the sensor is located at the limit position where the belt can run. In normal condition, the belt does not contact the deviation detection rod, and the two terminal blocks of the sensor are not connected; when the belt deviation contacts the deviation probe rod and pushes the probe rod to deviate from the normal position by 30 ° ± 3 °, the two terminal blocks of the sensor are connected.
3.1. Contact capacity: 24 V / 0.5 A;
3.2. Contact resistance: the contact resistance of closed contact shall not be greater than 0.1 Ω, and shall not be greater than 0.2 Ω after vibration, impact and service life;
3.3. Movement angle: 30 °± 3 °, reset angle: 10 °± 3 °;
3.4. Action force of probe rod: 25n-100n;
3.5. The limit angle of probe rod rotation is not less than 70 °
4. Working principle
The deviation detection rod of the sensor is located at the limit position where the belt can run. In normal condition, the belt does not contact the deviation detection rod, and the two terminal blocks of the sensor are not connected; when the belt deviation contacts the deviation probe rod and pushes the probe rod to deviate from the normal position by 30 ° ± 3 °, the two terminal blocks of the sensor are connected.
