1.We can handle small size component 0201, and BGA with 0.25mm distance and connector with 0.2mm distance;
2.The base material of PCB board we use are high quality;
3.We can manufacture Rigid PCB, Flexible, Rigid-flex, HDI board, High TG PCB;
4.Manufacture PCB board up to 32 layer, Raw material: Fr4, Rogers, Arlon, Teflon, Taconic, Nelco, Isola, Ceramic, Metal core.
More information, please feel free to contact us.

Items
Capability-Aluminum PCB
Laminates
CEM-1/3, FR4, Ceramic, Aluminum, PI, PET, Rogers
Layers
2 Layers
Max Size
600mm X 350mm
Board Thickness
0.2-3mm
Finished Copper
0.5oz - 2oz
Min.Line Width
5mil
Min.Line Space
3mil
Max.Aspect Ratio
10:1
Thermal Conductivity(w/mk)
1.0； 2.0； 3.0； 10.0－80.0
Surface finish
HAL(Tin-lead/lead free), ENIG, OSP, Silver plating
Capability-Rigid PCB
Laminates
FR4(TG130, TG150, TG170),
High frequency,无卤素Halogen free,
Aluminum base
Max Size
1-32Layers
Min.Board Thickness
2L:0.20mm, 4L: 0.40mm, 6L:0.60mm, 8L:0.80mm, 10L:1.20mm
Finished Copper
Inner:12-175um
Outer:35-350um
Min.Line Width
3/3mil
Min.Line Space
0.075/0.075mm
Max.Aspect Ratio
10:1
Hole Position Tolerance
+/-2mil
Surface finish
HAL(Tin-lead/lead free), ENIG, OSP, Immersion Silver, Gold plating, Gold fingers.

In order to make sure the delivery products are 100% good, we have strick quality control, suh as IQC incoming inspection, SPI solder paste inspection, Online AOI testing, SMT first piece inspection, IPQC product inspection, Offline AOI detection, X-RAY-welding inspection, QC manual inspection, and QA shipment inspection.

Q1:Are you a factory or trade company?
A: Yes, we are the factory, we have our own PCB manufacturing & Assembly factory.
Q2:What kind of PCB file format can you accept for production?
A:Gerber, PROTEL 99SE, PROTEL DXP, POWER PCB, CAM350, GCCAM, ODB+(.TGZ)
Q3:Are my PCB files safe when I submit them to you for manufacturing?
A:We respect customer's copyright and will never manufacture PCB for someone else with your files unless we receive written. Permission from you, nor we'll share these files with any other 3rd parties.
Q4:No PCB file/Gbr file, only have the PCB sample,can you produce it for me?
A: Yes,we could help you to clone the PCB. Just send the sample PCB to us, we could clone the PCB design and work out it.
Q5:What is Chuante lead time?
A:Sample:
1-2 Layers: 5 to 7working days
4-8 Layers: 12 working days
Mass production:
1-2 Layers:7 to 15 working days
4-8 Layers:10 to 18 working days
The leadtime is depends on your final confirmed quantity.
Q6:What payment do you accept ?
A:-Wire Transfer(T/T)
-Western Union
-Letter of Credit(L/C)
-Paypal
-Ali Pay
-Credit Cart
Q7:How to get the PCBs?
A:For small packages, we will ship the boards to you by DHL,UPS,FedEx,EMS. Door to door service! You will get your PCBs at your home.
For heavy goods more than 300kg, we may ship your PC boards by ship or by air to save freight cost. Of course, if you have your own forwarder, we may contact them for dealing with your shipment.
Q8:What is your minimum order quantity?
A: No MOQ.
Q9:How about your factory production capacity?
A:we can provide 100000 square meter/month.
Q10:Which countries have you worked with?
A:US, Canada, Italy, Germany, Czech Republic, Australia, Japan, and so on.
