基本信息
型号/编号 | h05rn-f h07rnf |
电压 | 450/750伏特,300伏特/500伏特 |
标准 | VDE EU Ieca、BS、DIN等 |
运输包 | 由出口木鼓或其他方式 |
规格 | 1.5-800平方毫米 |
商标 | 国旺 |
起源 | 中国 |
商品编码 | 8544492100 |
生产能力 | 每周五百万 |
产品详情
Product Description
Muti cores 25mm flexible h05rn-f h07rnf pur mining soft pump silicone rubber cable
No
Item
Data
1
Voltage:
450/750V
2
Insulation Material:
Rubber
3
Conductor:
Copper
4
Conductor Type:
Flexible
5
Sheath:
Rubber
H07RN-F Cable Construction:
Conductor:
Stranded Bare Copper acc. to IEC 60228, EN 60228, VDE 0295, class 5
Insulation:
Synthetic Rubber, EI4 acc. to DIN VDE 0282 part 1 + HD 22.1
Conductor Color Coding:
acc. to HD 308 (VDE 0293-308)
Conductor Stranding:
from 2 conductors stranded in layers
Jacket:
Synthetic Rubber, EM2 acc. to DIN VDE 0282 part 1 + HD 22.1
Jacket Color:
Black
H07RN-F Cable Technical Data:
Nominal Voltage:
Uo/U 450/750 volts
Testing Voltage U:
2500 volts acc. to DIN VDE 0282 part 2 + HD 22.2
Min. Bending Radius:
15 x O.D.H07RN-F Cable
Ratings & Approvals:
Temperature Range:
-25°C to +60°C
VDE
CE
Working voltage and temperature:H07RN-F
model rated voltage U0/U IS 450/750V
H05RN-F
model rated voltage U0/U IS 300/500V
H05RR-F
model rated voltage U0/U IS 300/500V
Long time allow working temperature of wire core cant be higher than 6
The Characteristics of the Product :
A.Soft with good bending performance .B.Using natural rubber or mixture neoprene as sheath material , can be applied to different occasions .C.Mixture of chloroprene rubber sheath is heat resistant , oil resistant , and don't delay burning performance .D.The maximum working temperature is 65°C .Packaging & Shipping
Other Hot Products
Company Profile
Henan Guowang Cable Co., Ltd.,
which was founded in 1992, is located in Zhengzhou City, Henan Province, China, with convenient
railway and air transportation. We are close to Shanghai, Qingdao and Tianjin Ports. Zhengzhou Yilan Cable Co., Ltd. is a
professional manufacturer of various electric wires and cables. Our products are supplied to customers from all over the world.Our company has 460 staff members, among whom 60 are engineers and technicians. Many advanced equipment and facilities are
imported from Germany, America and UK, helping us to achieve the annual output capacity of 1.2 billion pieces. With a perfect
quality management system and a good reputation, our company has developed into a modern enterprise specialized in the R&D,
manufacture and sale of electric wires and cables, including XLPE cables, armored cables, shielding cables, controlling cables and
so on. In China, our products have been used in the energy field, transportation field, communication field and so on. In recent
years, we have built happy cooperation with many customers in Asia, Africa and Europe.If you want to know more information about
us, please feel free to contact us.FAQ
Q:
Are you the trading company or Manufacturer?
A:
We are a professional & quality-guaranteed
manufacturer, and
we
can
supply factory price to you.Q: What certificates do your products carry?
A: We're a certified CE,CCC,ISO9001,ISO14001 factory company. All our products comply strictly with
international standard
or agreement made from the contract.Q:
Can we still contact you for any after sale customer service?
A:
Yes. We not only offer products but can also give
expert technical
advice. You're more than welcome to contact us for quality control, technical advice and any other
inquires.Q:
What's your payment terms?
A:
T/T,L/C,Western Union,etc.Q:
Is OEM is accpeted?
A:
Yes!
Q:
Do you offer free sample?
A:
Yes, we're more than happy to do so upon freight fee paid.
Muti cores 25mm flexible h05rn-f h07rnf pur mining soft pump silicone rubber cable
No
Item
Data
1
Voltage:
450/750V
2
Insulation Material:
Rubber
3
Conductor:
Copper
4
Conductor Type:
Flexible
5
Sheath:
Rubber
H07RN-F Cable Construction:
Conductor:
Stranded Bare Copper acc. to IEC 60228, EN 60228, VDE 0295, class 5
Insulation:
Synthetic Rubber, EI4 acc. to DIN VDE 0282 part 1 + HD 22.1
Conductor Color Coding:
acc. to HD 308 (VDE 0293-308)
Conductor Stranding:
from 2 conductors stranded in layers
Jacket:
Synthetic Rubber, EM2 acc. to DIN VDE 0282 part 1 + HD 22.1
Jacket Color:
Black
H07RN-F Cable Technical Data:
Nominal Voltage:
Uo/U 450/750 volts
Testing Voltage U:
2500 volts acc. to DIN VDE 0282 part 2 + HD 22.2
Min. Bending Radius:
15 x O.D.H07RN-F Cable
Ratings & Approvals:
Temperature Range:
-25°C to +60°C
VDE
CE
Working voltage and temperature:H07RN-F
model rated voltage U0/U IS 450/750V
H05RN-F
model rated voltage U0/U IS 300/500V
H05RR-F
model rated voltage U0/U IS 300/500V
Long time allow working temperature of wire core cant be higher than 6
The Characteristics of the Product :
A.Soft with good bending performance .B.Using natural rubber or mixture neoprene as sheath material , can be applied to different occasions .C.Mixture of chloroprene rubber sheath is heat resistant , oil resistant , and don't delay burning performance .D.The maximum working temperature is 65°C .Packaging & Shipping
