Electroluminescent Phosphor ( EL ) is a inorganic material that converts electric energy to lights directly, being widely applied to EL glass panel, enamel panel, plastic panel , EL wire , DC and AC EL lighting instruments . its main glowing color include Blue, Green, Orange, and their transition color.
As now main EL panel making tech apply screen printing and spray, EL phosphor we manufacture are divided into 3 types as below:
TYPE B: Average particle size 29μm, high brightness, heat resistance, suitable for application to plastic and enamel panel.
TYPE S: Average particle size 9μm, better brightness, homogeneous emitting effect, suitable for application to glass and plastic panel.
TYPE C:Average particle size 29μm, With characteristic of particle surface being coated, it has good humidity resistance, prolonged application lifetime , high brightness, no need of sealed package, suitable for application to plastic panel.

MODEL
TYPE
LIGHTING COLOR
CHEMICAL COMPONENTS
TK310
B
Blue-white
ZnS:Cu, YAG
TK320
S
Yellow-white
ZnS: Cu , Mn
TK330
B, S
Orange-white（white）
ZnS: Cu, Dye
TK417
B, S
Dark Blue
ZnS: Cu, Al
TK447
B, S
Light Blue
ZnS: Cu
TK502
B, S
Blue-green
ZnS: Cu
TK512
B, S, C
Green
ZnS: Cu
TK522
S
Yellow-green
（Zn, Cd）S: Cu
TK601
S
Yellow
（Zn, Cd）S: Cu
TK611
B, S
Orange-white（white）
ZnS: Cu, Mn
TK651
S
Orange-Red
ZnS: Cu, Mn
TK661
S
Red
（Zn, Cd）（S, Se）: Cu

Reference tech data for kinds of EL display applied of the special material is :
Voltage 40V-400V, Frequency 50Hz-4KHz, Temperature from under zero 40 to 60 centigrade degree, Current 0.02-0.2mA/ cm2, Electric Capacity 0.2-0.7nF/cm2, humidity 0%～90%， Power Consumption 2-7mW/ cm2, Application lifetime over 1000-20000hrs, Brightness 5-100cd/ m2

TYPE
APPLICATION
CHARACTERISTIC
Paste A(glue)
Lighting Layer Printing
Mix with EL phosphor, with strong adherence, Keep dry within 3-4 Hrs under 110 centigrade degree
Paste B(glue)
Median Layer Printing
Mix with median power , improve conductivity, Keep dry within 3-4 Hrs under 110 centigrade degree
Median Power(Carrier)
Median Layer Printing
High reflectivity, High conductivity
Property-adjustable Solvent
Additive for A, B Paste
Solidify Improvement
Diluter, Wash thinner
Viscidity Adjusting, Washing Tool
Dilution, Washing
ITO Film
Transparent Plastic Electric Film
Transparent, Flexible
ITO ink
Transparent Plastic Electric Film
Transparent, Flexible
Paste AB(glue)
Lighting and Median Printing
Easier and Prompt Application Be dry within 20 minutes with 110 centigrade degree
Electric Paste
Back Electrode Printing
Good Conductibility
Insulating Coating
Back Electrode Protection
Easier Application
