Offshore Modular Fabrication system, designed for offshore jacket substructure fabrication
1. Steel Plate Pre-treating System
automatic steel plate blasting and painting machine
2. Plate To Single Shell Fabrication
CNC plate cutting machine
edge beveling machine
edge pre-bending machine
plate rolling machine
Preheating machine
internal & external longitudinal seam automatic welding machine
back
seam gouging
and single shell rerolling machine
3. Multi Single-shells To 12m Shell Fabrication
shell to shell fitting-up to 12m length machine
Preheating machine
internal circular seam automatic welding machine
back seam gouging machine
external circular seam automatic welding machine
conveying equipments to next work steps
4. Shell and Shell Growing Up Machine
SAW welding machine for dish-end
Shell and Shell Growing Up Machine
In offshore project fabrication, there are different work pieces should be fabricated, such as Jacket Fabrication, H-beam fabrication, Pipe Pile / Pipe Rack fabrication and pipeline fabrication. For different work pieces, NAEC has different fabrication solutions.NAEC begin to develop offshore Pipe Pile / Pipe Rack fabrication equipments and technologies since year 2006. We believe by move main fabrication job in workshop with logical fabrication workflow and efficient handling system will highly improve the fabrication efficiency and further improve customer's profit.Offshore Pipe Pile / Pipe Rack workpiece is rolled from a steel plate with approximate length 3M. In our design we suggest single 3M length sections can be fitted-up to a 12M length shell. And the 12M shell can be extended to required length. We integrated advanced and high efficient fabrication technology such as tandem welding and multi-wire welding into our design, designed machines suitable for different seams welding. Such whole planning and design has been implemented in the offshore fabrication base of CNPC.Our offshore pipe pile / pipe rack fabrication solution cover from plate cutting, plate edge milling, shot blasting and painting, plate rolling, longitudinal seam welding, section fitting-up, pretreatment, circumferential seam welding, shell fitting-up and extension, Non-destructive testing solution. Our present offshore pipe pile/pipe rack fabrication capability suitable for pile/ rack diameter range from 500mm to 5000mm.Such system has successfully operated in CNPC QINGDAO OFFSHORE BASE
