基本信息
| 型号（NO.） | 环氧聚酯粉末涂料 |
| 颜色 | “绿色” |
| 外观 | 粉末 |
| 主要原材料 | 环氧树脂 |
| 等级 | 底漆 |
| 方法 | 喷雾 |
| 认证 | ISO14001、CCC、RoHS、ISO9001 |
| 基质 | 钢 |
| 组件 | 颜料 |
| 形成机制 | 转化类型 |
| 有效期 | 1年 |
| 使用 | 金属表面涂层 |
| Texture：纹理 | “温克尔”（Winkle） |
| 光泽的 | 高光泽度 |
| 存储条件 | 36c以下 |
| 运输包 | 纸箱包装 |
| 规格说明 | 25公斤 |
| 商标 | 绚丽的 |
| 起源 | 中国 |
| 商品编码 | 3907999000 |
| 生产能力 | 每年5000吨 |
产品详情
Product Description
Powder coatings have advantages such as no organic solvents, environmental friendliness (compared to oil-based coatings), high material utilization, low energy consumption, and are easy to apply with low cost. They have good corrosion and weather resistance and are suitable for products and facilities with low requirements for corrosion and weather resistance. They have been widely used in many fields of manufacturing. Among them, polyester powder coatings are widely used in outdoor facilities such as buildings, automobiles, and transportation due to their excellent comprehensive performance and relatively low cost advantages. Currently, more than half of thermosetting powder coatings are prepared using polyester resin as the base material."Polyester-TGIC" is a series of polyester based powder coatings with the use of TGIC
Designed for exterior or interior use.Offering excellent light and weatherability from a single coat finish on a variety of substrates.This series are available in a wide range of colors with different gloss and texture.Main properties:excellent UV resistance for exterior application;Good heat resistance
Product Parameters
Chemistry: Polyester-TGIC
Particle size: Suitable for electrostatic spray
Storage: Dry ventilation conditions below 30ºC
Curing schedule: 200ºC/10minutes;190ºC/15minutes
Specific gravity: 1.2-1,8g/cm3
up to colors
TECH DATA SHEET
Specific gravity (g/cm³, 25 ºC): 1.4-1.7
Particle size distribution: 100% less than 100 microns (adjustable according to special coating requirements)
Curing conditions: 200 ºC, 10 minS
Testing items
Testing standards
Inspection indicators
High gloss
Semi Gloss
Matt
Impact resistance
GB/T 1732-1993
50kg.cm
40kg.cm
40kg.cm
Cupping test
GB 9753-1988
8mm
7mm
7mm
Adhesion
GB/T 9286-1998
0 Level
Bending test
GB 6742-1986
2mm
3mm
3mm
Hardness
GB/T 6739-1996
1H-2H
Heat resistance
GB 1740-1989
>1000H
Weather resistance
150ºC*24H
Excellent light retention, color difference ≤ 0.3-0.4
Glossy Durable Polyester Powder Coating
Transparent Polyester Powder Coating
Matt Durable Polyester Powder Coating
Super Matt Polyester Powder Coating
Installation Instructions
Detecting Instrucment
Certifications
Powder coatings have advantages such as no organic solvents, environmental friendliness (compared to oil-based coatings), high material utilization, low energy consumption, and are easy to apply with low cost. They have good corrosion and weather resistance and are suitable for products and facilities with low requirements for corrosion and weather resistance. They have been widely used in many fields of manufacturing. Among them, polyester powder coatings are widely used in outdoor facilities such as buildings, automobiles, and transportation due to their excellent comprehensive performance and relatively low cost advantages. Currently, more than half of thermosetting powder coatings are prepared using polyester resin as the base material."Polyester-TGIC" is a series of polyester based powder coatings with the use of TGIC
Designed for exterior or interior use.Offering excellent light and weatherability from a single coat finish on a variety of substrates.This series are available in a wide range of colors with different gloss and texture.Main properties:excellent UV resistance for exterior application;Good heat resistance
Product Parameters
Chemistry: Polyester-TGIC
Particle size: Suitable for electrostatic spray
Storage: Dry ventilation conditions below 30ºC
Curing schedule: 200ºC/10minutes;190ºC/15minutes
Specific gravity: 1.2-1,8g/cm3
up to colors
TECH DATA SHEET
Specific gravity (g/cm³, 25 ºC): 1.4-1.7
Particle size distribution: 100% less than 100 microns (adjustable according to special coating requirements)
Curing conditions: 200 ºC, 10 minS
Testing items
Testing standards
Inspection indicators
High gloss
Semi Gloss
Matt
Impact resistance
GB/T 1732-1993
50kg.cm
40kg.cm
40kg.cm
Cupping test
GB 9753-1988
8mm
7mm
7mm
Adhesion
GB/T 9286-1998
0 Level
Bending test
GB 6742-1986
2mm
3mm
3mm
Hardness
GB/T 6739-1996
1H-2H
Heat resistance
GB 1740-1989
>1000H
Weather resistance
150ºC*24H
Excellent light retention, color difference ≤ 0.3-0.4
Glossy Durable Polyester Powder Coating
Transparent Polyester Powder Coating
Matt Durable Polyester Powder Coating
Super Matt Polyester Powder Coating
Installation Instructions
Detecting Instrucment
Certifications
