1.1. Features
* Working Voltage: 2.7~5.5V
*Operating temperature: -40ºC~+85ºC
*Storage temperature: -40ºC~+125ºC
*
15K FLASH
*1K EEPROM
*256Bytes(data)+512(xdata)SRAM
*Built-in RC oscillation circuit (1 MHz)
*High speed 8051, based on standard 8051
instruction pipelining structure
*
Operating frequency (software configurable:
12M, 6M, 4M system clock, one clock / machine cycle, 9 / 12 times faster than the
ordinary
*Capacitor keys can be used as GPIO
*GPIO supports built-in pull up resister
*16 bit PWM output module, PWM0 support IO
mapping output
*8*8,7*8,7*7,6*7,6*6,5*5,4*4 LED serial dot
matrix driver
*8 large sink current port.
*3*16 bit timers overflow interrupt; Timer 2
using the internal 32KHz or an external crystal
32768Hz/4MHz
*INT0~2 external interrupts (rising, falling, rising and falling)
*Support idle mode, Wake-up time: 0.1s~2.304s
*12-bit 10 bit precision ADC detection
*In low power mode all keys can be paralleled as
wake-up key (<20uA@100ms)
*IIC slave mode, standard mode
100/400KHz
*2-way independent UART, Baudrate
(2400, 4800, 9600, 19200, 57600,
115200) support IO mapping
*Two levels of interrupt priority are
optional
*Interrupts:
--Capacitive button interrupt
--ADC interrupt
--LED interrupt
--External interrupt
--Timer0, Timer1, Timer2
--UART interrupt
--IIC communication interrupt
--WDT interrupt
--LVDT interrupt
*Support power off reset (2.1V)
*Low voltage detection
2.4V/3.0V/3.6V/4.2V
*
WDT, overflow time: 18ms~2.304s
*
Deep sleep and power consumption 6uA
@5V
*Sensitivity can be flexibly configured
*With JTAG debug simulation interface
*Packages:

SOP16/SOP20/TSSOP20/QFN20/SOP28/TSSO P28
1.2. Overview
BF7612BMXX uses the high speed 8051 core with 1T instruction cycle, compared to the
standard 8051 (12T) instruction cycle, has the quicker running speed, compatibility standard 8051
instruction.BF7612BMXX includes a watchdog, key detection, LED serial dot matrix driver, IIC, UART,
low voltage detection, power down reset, 3-channe l6bit PWM, Timer0, Timer1, Timer2, 12bit
10-bit successive approximation ADC, low power mode.BF7612BMXX integrated capacitance channels, which can be used to detect proximity sensing
or touch, its built-in MCU, can be flexible configurated, through the configuration can be
implemented keys, rollers, sliders and other applications. A key can be run independently, and each
key can be adjusted by corresponding special function registers to adjust the sensitivity
