High Quality DC Brushless Motor Driver 220V Output Current: 12A, Suitable for 3000W Motor

Preview

Basic Info.Product DescriptionCertifications

Basic Info.

Model NO.	LKDBLS-07-K
Continuous Output Current	12A, Suitable for ≤3000W Motor
Max. Current	22A (3sec Stop)
Working Temp	0~+45°c
Storage Temp	-20~+85°c
Working & Storage Humidity	<85% (No Frosting)
Structure	Wall-Mountable Type
Cooling	Radiator
Control Terminals	Isolation
Specification	301515
Trademark	Lulanjiu
Origin	China
Production Capacity	1000
Package Size	30.00cm * 15.00cm * 15.00cm
Package Gross Weight	3.500kg
Package Size	30.00cm * 15.00cm * 15.00cm
Package Gross Weight	3.500kg

Product Description

Preview

High quality DC brushless motor driver 220V Output Current: 12A, Suitable for 3000W motor
Products Description
LKDBLS-07-K BLDC motor driver is designed by Dingtuo Technology independence which is assorted with the advanced motion control industrial. It is suitable for BLDC motor with the power under 3000W. The driver adopts the latest high performance digital logic chips specialized for brushless motors. It uses a new type of PWM technology that enable the motor running high speed, small vibration, low noise, good stability and high reliability.
Product Paramenters
System Characteristic:
Basic Characteristic:
Cooling: Radiator Control terminals: Isolation Work mode: speed open loop, speed closed loop, external interface control, panelmanual control, sense mode, no sense mode, external analog voltage speed regulation, external PWM signal speed regulation, speed display, current effective value display, maintenance mode. Protection: Over load, over heat, over speed, over voltage, under voltage will cause the power abnormal.
