FEATURES
·Excellentlinearity
·Extremelylownoise
·Highgain
·Excellentreturnlossproperties.
APPLICATIONS
·SinglemodulelineextenderinCATVsystemsoperating
overafrequencyrangeof40to860MHz.
DESCRIPTION
Hybridhighdynamicrangeamplifiermoduleoperating
withavoltagesupplyof24VinaSOT115Jpackage.The
highgainmoduleconsistsoftwocascadedstagesbothin
cascodeconfiguration.
PINNINGSOT115J
PINDESCRIPTION
1input
2,3common
5+VB
7,8common
9output
QUICKREFERENCEDATA
LIMITINGVALUES
InaccordancewiththeAbsoluteMaximumRatingSystem(IEC134).
SYMBOLPARAMETERCONDITIONSMIN.MAX.UNIT
Gppowergainf=50MHz33.534.5dB
f=860MHz34-dB
Itottotalcurrentconsumption(DC)VB=24V-340mA
SYMBOLPARAMETERMIN.MAX.UNIT
ViRFinputvoltage-55dBmV
Tmboperatingmountingbasetemperature-20+100°C
Tstgstoragetemperature-40+100°C
MODEL
Frequency
MHz
Gain
dB
Voltage
V
Current
mA
Slope
dB
Flatness
dB
Input
reflection
dB
BGY67A
5~200
23.5~24.5
24
140~160
1.0~1.5
±0.3
≥20
BGY68
5~200
29.5~30.5
24
190~210
1.0~1.5
±0.3
≥16
NEC7884S
40~870
25~26
24
340~360
1.0~1.5
±0.3
≥16
NEC7883S
40~870
25~26
24
340~360
1.0~1.5
±0.3
≥16
NEC7882S
40~870
25~26
24
340~360
1.0~1.5
±0.3
≥16
NEC7881S
40~870
25~26
24
340~360
1.0~1.5
±0.3
≥16
BGY588C
40~550
33.5~34.5
24
290~320
1.0~1.5
±0.3
≥16
BGY785A
40~750
17.5~18.5
24
190~210
1.0~1.5
±0.3
≥16
BGY787C
40~750
21.5~22.5
24
290~320
1.0~1.5
±0.3
≥16
BGY787B
40~750
29.5~30.5
24
290~320
1.0~1.5
±0.3
≥16
BGE788C
40~750
33.5~34.5
24
290~320
1.0~1.5
±0.3
≥16
BGD712C
40~750
18~19
24
190~210
1.0~1.5
±0.3
≥16
BGD714
40~750
19~20
24
190~210
1.0~1.5
±0.3
≥16
BGY885A
40~860
17.5~18.5
24
190~210
1.0~1.5
±0.3
≥16
BGY887C
40~860
21.5~22.5
24
290~320
1.0~1.5
±0.3
≥16
BGY887B
40~860
29.5~30.5
24
290~320
1.0~1.5
±0.3
≥16
BGY888C
40~860
33.5~34.5
24
290~320
1.0~1.5
±0.3
≥16
BGD812C
40~860
18~19
24
190~210
1.0~1.5
±0.3
≥16
BGD814C
40~860
19~20
24
190~210
1.0~1.5
±0.3
≥16
BGY1018C
40~1000
17.5~18.5
24
190~210
1.5~2.0
±0.5
≥16
BGY1044
40~1000
21.5~22.5
24
290~320
1.5~2.0
±0.5
≥16
BGY1034C
40~1000
33.5~34.5
24
290~320
1.5~2.0
±0.5
≥16
BGE887BO
40~860
19~20
24
190~210
2.0~2.5
±1.0
