Basic Info.Product Description
Basic Info.
Model NO. | HGH |
Length | 4~6m |
Material | Steel |
Precision Grade | 1/2/3/4/5 |
MOQ | 1 |
Samples | Available |
Structure | Hook Crane |
Installation | Roughterrain Wheeled Crane |
Driven Type | Hydraulic |
Running Mode | Moving |
Feature | Insulating, Antiseptic |
Transport Package | Be Rust Protected and Packed for Over Sea |
Specification | 16-85 |
Trademark | RYJ MOTION |
Origin | Nanjing |
Package Size | 120.00cm * 30.00cm * 15.00cm |
Package Gross Weight | 10.000kg |
Package Size | 120.00cm * 30.00cm * 15.00cm |
Package Gross Weight | 10.000kg |
Product Description
Product Description
Preview
Product description
GGB is the earliest developed LM guide and is one of the widely used guides. Design with equal 45° contact angle, which makes equal load in vertical upside ,vertical downside, horizontal left and horizontal right four orientations, and it has heavy rated load, good rigidity, high sifness and strong torque resistance of three directions, so it also calls four direction equal load LM guide.
As the most widely used linear guide,our products can replace HIWIN/PMI/THK ball type linear guide, such as HGW/MSA/HSR and so on.Our products are widely exported to countries all over the world.
Specifications
Ball type:HGH15 - HGH65Normal accuracy is interchangeable Maximum motion accuracy 0.004/1000Can meet the fast deliveryMax. Single length 6mHigh speed Low noise It's widely used in Machining center, NC lathe machine, wire spark machine, portage device, wood machinery, laser machine, precision test instrument, packing machine, food machinery, medical machinery, tool grinding machine, plane grinding machine.
GGB is the earliest developed LM guide and is one of the widely used guides. Design with equal 45° contact angle, which makes equal load in vertical upside ,vertical downside, horizontal left and horizontal right four orientations, and it has heavy rated load, good rigidity, high sifness and strong torque resistance of three directions, so it also calls four direction equal load LM guide.
As the most widely used linear guide,our products can replace HIWIN/PMI/THK ball type linear guide, such as HGW/MSA/HSR and so on.Our products are widely exported to countries all over the world.
Specifications
Ball type:HGH15 - HGH65Normal accuracy is interchangeable Maximum motion accuracy 0.004/1000Can meet the fast deliveryMax. Single length 6mHigh speed Low noise It's widely used in Machining center, NC lathe machine, wire spark machine, portage device, wood machinery, laser machine, precision test instrument, packing machine, food machinery, medical machinery, tool grinding machine, plane grinding machine.
Preview

Preview

Preview

Preview

Preview

Preview
China Linear Guide HGH Type Replace Hiwin
$4.99
Smart Device Industry Chain · Transmission Device · Guide Rail
Model NO.:HGH
Transport Package:Be Rust Protected and Packed for Over Sea
Origin:Nanjing
