High Precision PTN60 Hollow Rotary Platform
Specificaitons:1)Product size: 60
2)Ratio range:5/10
3)Motor range: type 42
(stepper motor)
50/100W AC
(servo motor)
4)Input installation size code: 830M345LR30 (ratio:5/10);
830M446LR30 (ratio:5/10);
5223.543.8LR30 (ratio:5/10)
5)Work objects can be directly locked: the rotating disk surface can directly lock the work objects to improve the convenience of workpiece loading;
6)Convenient wiring: the rotary platform is of hollow design, which is convenient for wiring or piping;
7)High accuracy: the positioning accuracy is less than 1arcmin; The repetition accuracy can reach ± 5arcsec;
8)Stable operation: the panel rotates smoothly and smoothly, and the cutting and positioning is fast
