Features
RoHS compliant
Seal type
Small volume
Structural diversification
High quality
Application
Indeal for volume control and car amplifier,walkie-talkie.Switch performance
circuit type: Push
Rated Power: 0.1A 5V DC
Switching torque: 500gf.cm max
Switching travel: 1.5±0.5mm
Operating life without load: 100,000cycles 100mΩ
max
Operating life with
load: as rating 100,000cycles 200mΩ
max
Initial contact resistance: 100mΩ max
Insulation resistance :
100mΩ max min. 250V DC
Voltage proof: 300V AC for 1 minute
Mechanical characteristics
Total rotational angel: Incremental:360°
Logic:300°±5º
Rotational torque: 150~350gf.cm
Rotational stopper strength :3Kgf.min
Shaft push-pull strength: 8Kgf.max
Shaft wobble: Max:0.6*L/20mm P-P max.Electrical characteristics
Ratings power: 0.025W
Insulation
resistance : 100mΩ min.250V DC
Voltage proof:
300V AC for 1 minute
Durability
Operating life without load: 20,000 cycles 100mΩ max.Environmental performance
Cold: -40ºC±2ºC for 96h
Dry heat: 85ºC±2ºC for 96h
Damp heat: 40±2ºC, 90 to 95%RH for 96H
