productPhotoelectric Proximity Sensor C3jk-D30np NPN PNP Low Error Detection Distance 30cm Photoelectric Sensor
Image 2Image 3Image 4Image 5Image 6
Image 1
Preview
Basic Info.Product DescriptionCertifications

Basic Info.

Model NO.C3JK-D30NP
FeatureCorrosion Resistant
IP RatingIP67
CertificationCE
CustomizedCustomized
Residual Voltage<2
Response Time<2ms
Retturn DifferenceLess Than 15% of Detection Distance
Supply VoltageDC10~30V
Protection CircuitDC(NPN,PNP): Polarity, Overcurrent Protection
Ambient Illuminance RangeIncandescent :Spot Intensity 200,000lx or Less
Sensinf Surface MaterialPC
Detectable ObjectsRegkecting Object
Transport PackageCarton or Plywood Case
TrademarkWEHO
OriginZhejiang
Production Capacity50000/Year
Package Size2.00cm * 6.00cm * 6.00cm
Package Gross Weight0.500kg
Package Size2.00cm * 6.00cm * 6.00cm
Package Gross Weight0.500kg

Product Description

Product Description
detail
Preview
Photoelectric Proximity Sensor C3JK-D30NP NPN PNP Low error Detection Distance 30cm Photoelectric Sensor
Features:
detail
Preview
detail
Preview
detail
Preview
detail
Preview
detail
Preview
detail
Preview

Certifications

Name:Main certificate portfolio
Preview
Contact Us
Send an E-mail to：support@bincial.com
Photoelectric Proximity Sensor C3jk-D30np NPN PNP Low Error Detection Distance 30cm Photoelectric Sensor
$10.55 ~ $12.27
Smart Device Industry Chain · Sensors and Detection Elements · Photoelectric Sensor
Model NO.:C3JK-D30NP
Transport Package:Carton or Plywood Case
Origin:Zhejiang
