Basic Info.
| Model NO. | 6650 |
| Maximum Voltage | 10KV~20KV |
| Thermal Rating | H 180 |
| Usage | for Transformer and Motors |
| Width | 10-910mm, Accept Customization |
| Product Name | 6650 Nomex Paper |
| Temperature Resistance | 180/200 Degre |
| Film | Polyimide Film |
| Type | Insulation Paper |
| Chemistry | Organic Insulation |
| Certification | ISO9001, RoHS |
| Classification | Nhn |
| Brand | Henan Jinzhi |
| Transport Package | Carton/Pallet |
| Specification | 0.15-0.35mm |
| Trademark | JINZHI |
| Origin | Xuchang, Henan |
| Production Capacity | 12000 Metric Ton/Metric Tons Per Year |
| Package Size | 15.00cm * 20.00cm * 10.00cm |
| Package Gross Weight | 1.200kg |
| Package Size | 15.00cm * 20.00cm * 10.00cm |
| Package Gross Weight | 1.200kg |
Product Description
1. NHN 6650 insulation paper composition
NHN/NKN (Nomex paper/Polymide film/Nomex paper)is a Triple layer electrical insulation material of thermal class H 180ºC, consisting of polymide film covered with Du Pont Nomex paper. The polymide film giving the product mechanical and dielectric features, while the Du Pont Nomex paper gives the thermal resistance.This NHN has excellent electrical.mechanical,and impregnating properties.
2. NHN 6650 insulation paper application
This 6650 NHN insulation paper is suitable for slot insulation, turn-to-turn insulation and gasket insulation for Class H high heat resistance motor appliances , such as cables, coils, motors, generators, ballasts, etc., and is used for interlayer insulation of transformers and other electrical appliances, such as dry-type transformers, high-voltage transformers, etc.
3. NHN 6650 insulation paper characteristics
a. Excellent mechanical properties: such as good tensile strength and edge tear resistance, electrical properties, dielectric properties, mechanical toughness, chemical compatibility, thermal conductivity, radiation resistance,
b. low moisture absorption rate, good moisture resistance
c. has excellent insulation properties.
d. insulating paint infiltration effect is strong.
e. Add some heat-resistant organic fiber, long-term withstand voltage at high temperature, excellent flame retardant and flame resistance, thermal stability, heat resistance and thermal conductivity.
f. the material is safe and non-toxic, and the shaping effect is excellent.
4. NHN 6650 insulation paper storage
The insulation meterial can be stored indefinitely under normal conditions and away from other humid material
NHN/NKN (Nomex paper/Polymide film/Nomex paper)is a Triple layer electrical insulation material of thermal class H 180ºC, consisting of polymide film covered with Du Pont Nomex paper. The polymide film giving the product mechanical and dielectric features, while the Du Pont Nomex paper gives the thermal resistance.This NHN has excellent electrical.mechanical,and impregnating properties.
2. NHN 6650 insulation paper application
This 6650 NHN insulation paper is suitable for slot insulation, turn-to-turn insulation and gasket insulation for Class H high heat resistance motor appliances , such as cables, coils, motors, generators, ballasts, etc., and is used for interlayer insulation of transformers and other electrical appliances, such as dry-type transformers, high-voltage transformers, etc.
3. NHN 6650 insulation paper characteristics
a. Excellent mechanical properties: such as good tensile strength and edge tear resistance, electrical properties, dielectric properties, mechanical toughness, chemical compatibility, thermal conductivity, radiation resistance,
b. low moisture absorption rate, good moisture resistance
c. has excellent insulation properties.
d. insulating paint infiltration effect is strong.
e. Add some heat-resistant organic fiber, long-term withstand voltage at high temperature, excellent flame retardant and flame resistance, thermal stability, heat resistance and thermal conductivity.
f. the material is safe and non-toxic, and the shaping effect is excellent.
4. NHN 6650 insulation paper storage
The insulation meterial can be stored indefinitely under normal conditions and away from other humid material
Brand Name Henan Jinzhi
Type 6650 HNH paper for motors
Material Dupont paper with polyimide film
Application electrical Insulating
Rated Voltage 7-23KV
thickness 0.15/0.17/0.20/0.23/0.25/0.30/0.35mm,accept customization
Certificate ISO9001/RoHS
Working temperature Class H, 180/200ºC
Sample Sample Available
Keywords insulation paper for motors
Delivery Within 30 Days
Type 6650 HNH paper for motors
Material Dupont paper with polyimide film
Application electrical Insulating
Rated Voltage 7-23KV
thickness 0.15/0.17/0.20/0.23/0.25/0.30/0.35mm,accept customization
Certificate ISO9001/RoHS
Working temperature Class H, 180/200ºC
Sample Sample Available
Keywords insulation paper for motors
Delivery Within 30 Days
Certifications
Name:ISO Certificate of mica product,composite material, high -performance fibers
